| Max Printing Width | 300 mm 12″ A3 DTF (Desktop Popular Model) | 420 mm 16.5″ A2 DTF | 600 mm 24″ A1 DTF / Standard 24″ Production | 800 mm 31″ 31″ Wide-format DTF for large pattern |
| Printhead | 2 Pcs Original Epson I3200-A1 | 2 Pcs Original Epson I3200-A1 | 2 Pcs Original Epson I3200-A1 | 2 / 4 Pcs Original Epson I3200-A1 |
| Max Printing Resolution | Up to 2400×2400 DPI |
| Ink Color | CMYK + White Pigment Ink |
| Ink Type | Eco-friendly DTF Textile Pigment Ink | | | |
| White Ink System | Auto circulation & stirring system, anti-precipitation & anti-clogging |
| Print Media | PET Transfer Film (Roll to Roll) |
| Printing Speed | 4Pass:12 m²/h; 6Pass:9 m²/h; 8Pass:6 m²/h | 4Pass:14 m²/h; 6Pass:10 m²/h; 8Pass:7 m²/h | 4Pass:16 m²/h; 6Pass:12 m²/h; 8Pass:9 m²/h | 4Pass:22 m²/h; 6Pass:16 m²/h; 8Pass:11 m²/h |
| RIP Software | Maintop / Photoprint / Cadlink optional |
| Operating System | Windows 10 / Windows 11 (64-bit) |
| Working Environment | Temperature:15–30℃, Humidity:35–65% non-condensing |
| Power Supply | AC 110V/220V, 50/60Hz |
| Certification | CE, RoHS Certified |
| Support Materials | Polyester, cotton blends, denim, nylon, PU leather, canvas, silk |
| Features | No pre-treatment needed; works for dark & light fabrics; transfer film can be stored |
